K40 Custom Conveyor Belt Mfg CLEANGEN® TPU
Retail price
市场价
Weight
Stock
隐藏域元素占位
Email：aline@cleangenbelting.com
- Product Description
-
- Commodity name: K40 Custom Conveyor Belt Mfg CLEANGEN® TPU
Food grade, antibacterial, anti-mildew and easy to clean，the center-driven design makes the conveying surface flatter and makes bottom cleaning easier.
Series (Gear Drive) Surface Pattern Color Belt Thickness (MM) Material Hardness Antibacterial Grade Tooth Height Maximum Load (kg/m²) Use Temperature Range (°C) Tooth Pitch Minimum Wheel Diameter (MM) S40-U30Y
S40-W30Y
Glossy Side Blue/White 3MM TPU (Polyester Material) 90A Level 1 8 220 Low Temperature -5 To High Temperature 80 39.7 101.15 H40-DU30Y
H40-MW30Y
Glossy Side Dark Blue/Milky White 3MM TPU (polyether Material) 90A Level 1 8 220 Low Temperature -20 To High Temperature 60 39.7 101.15 S40-U30
S40-W30
Glossy Side Blue/White 3MM TPU (Polyester Material) 50D Level 1 8 120 Low Temperature -5 To High Temperature 80 39.7 101.15 H40-DU30
H40-MW30
Glossy Side Dark Blue/Milky White 3MM TPU (polyether Material) 50D Level 1 8 120 Low Temperature -20 To High Temperature 60 39.7 101.15
| Series (Gear Drive) | Surface Pattern | Color | Belt Thickness (MM) | Material | Hardness | Antibacterial Grade | Tooth Height | Maximum Load (kg/m²) | Use Temperature Range (°C) | Tooth Pitch | Minimum Wheel Diameter (MM) |
|
S40-U30Y S40-W30Y |
Glossy Side | Blue/White | 3MM | TPU (Polyester Material) | 90A | Level 1 | 8 | 220 | Low Temperature -5 To High Temperature 80 | 39.7 | 101.15 |
|
H40-DU30Y H40-MW30Y |
Glossy Side | Dark Blue/Milky White | 3MM | TPU (polyether Material) | 90A | Level 1 | 8 | 220 | Low Temperature -20 To High Temperature 60 | 39.7 | 101.15 |
|
S40-U30 S40-W30 |
Glossy Side | Blue/White | 3MM | TPU (Polyester Material) | 50D | Level 1 | 8 | 120 | Low Temperature -5 To High Temperature 80 | 39.7 | 101.15 |
|
H40-DU30 H40-MW30 |
Glossy Side | Dark Blue/Milky White | 3MM | TPU (polyether Material) | 50D | Level 1 | 8 | 120 | Low Temperature -20 To High Temperature 60 | 39.7 | 101.15 |
